總 Slots 數 : 4 (2 通道) 總容量 : 最大至 128GB UDIMM 記憶體類型 : DDR4 2666/2400 UDIMM
non ECC and with ECC 記憶體大小: 32GB, 16GB, 8GB, 4GB UDIMM
硬碟機
可另行選購
硬碟機數量(標準/最大)
4 x 3.5” Hot-Swap HDD Bays 2 x SSD Internal SSD Bays 2 x M.2 (NGFF
22110/2280/2260/2242)
硬碟控制介面
SATA 控制器: Intel® C242 Chipset 6 x SATA3 6Gb/s 連接埠 *1 2 x M.2
connector(2242/2260/2280/22110) both SATA & PCIe mode *2 Intel® Rapid
Storage Technology Enterprise(RSTe) (For Linux/Windows) (Support
Software RAID 0, 1, 5, 10 ) SAS Controller : ASUS PIKE II 3008-8i 8-port
SAS 12G RAID card(選購) ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID
card(選購)
顯示介面
Aspeed AST2500 with 32MB VRAM
輸出入介面
(前面板) 2 x USB 3.0 ports 1 x VGA port
(後面板) 4 x RJ-45 ports 2 x USB 3.1 ports 2 x USB 3.0 ports 1 x VGA port 1
x External Serial Port 1 x RJ-45 ports (One for ASMB9-iKVM)(Optional)
擴充槽數量
Total PCI/PCI-X/PCI-E/PIKE Slots: 2 1 x PCI-E x16 (x8 Gen3 Link) 1 x
PCI-E x8 (x8 Gen3 Link)
電源供應器
Single 450W 80 PLUS Gold Power Supply Rating:
100-127Vac/200-240Vac,8A/4A ,47-63Hz, Class 1
